You can subscribe to this list. Attachments: Hi Joerg, Once again, thank you for your time and information. I will definitely give it a try, and hope that I don't fry my laptop and/or EEG, as a result of some misconnection. Not having to mess around with batteries will be a real help. Rechargeable battery technology just isn't where it needs to be, yet, and 'normal' batteries are too expensive to keep buying very often.

As you stated, this information will undoubtedly be of interest to many others who frequent this website, so I'm sure that you have helped several of us. Have a good day!

Game Controller Drivers Download Gaming systems are the most advanced PCs today. If you are having issues with getting your Game Controller to work, the problem could be missing or corrupt Game Controller Drivers.

--Ray Cole ----- Original Message ----- From: Joerg Hansmann To: Discussion of EEG hardware, software, training protocols, NFB theory - for developers and users. Sent: Wednesday, September 17, 2008 1:43 AM Subject: Re: [Openeeg-list] Battery Elimination--Second Try (ForgotAttachment) Hi, Ray Cole, 07:15: > > Hi Joerg, > > Thank you for your patience and replies; I appreciate your effort and > time in doing that. > > I have attached a quick sketch of what I think you have described, > regarding the second option for stealing some power from the USB cable. > Ist es richtig, oder nicht?

It looks perfectly OK. > I hope that you can open it. > > Oh, one more thing: When you said, 'Make sure you have patched the > ModularEEG for +5V supply. The unpatched > ModularEEG needs at least 7.5V for operation,' how do I do that? Unsolder IC107 (the 7805 voltage regulator) and solder a piece of wire from the left to the right pad of the 7805 footprint on the pcb. This connects IN with OUT and bypasses the regulator.

Additionally you have to unsolder or simply short D103. This is a diode that protects the modularEEG from reversed batteries. However it takes 0.7V away and that is not acceptable when we have only 5V.

Solder in D104 (if you have no spare one, you can use the D103 you have desolderd). This now is the new reverse polarity protection in shunt mode. Instead of blocking as D103 did, this one protects by the crowbar method: A reversed power supply is shorted to GND. Not so nice but better than no protection at all. You can omit D104 if you are very sure that the power polarity is always right. This is a valid assumption on USB cables. Regards, Joerg ------------------------------------------------------------------------- This SF.Net email is sponsored by the Moblin Your Move Developer's challenge Build the coolest Linux based applications with Moblin SDK & win great prizes Grand prize is a trip for two to an Open Source event anywhere in the world; _______________________________________________ Openeeg-list mailing list Openeeg-list@.; Go to the above address to change your subscription options, e.g unsubscribe.

Hi, Mike, 12:28: > The openEEG has been well designed to resist ESD damage. However, I have been > careless in the past.

I have left the electrodes connected to the openEEG > amplifier, and let them dangle. Should be no problem. Plugging in a charged cable is more likely to challenge the ESD protection. > This has led to one of the INA114 amplifiers > -ve inputs becoming damaged by ESD. Did you verify the defect by swapping the INAs from one channel to the other?
